Milling Machine OMV mod. BFC800
Sold
Milling Machine OMV mod. BFC800
Brugali, Italy
Description
Head with vertical spindle
Specifications
| Condition | Used |
| Length of the table | 1700 mm |
| Width of the table | 700 mm |
| Loading capacity on table | 3000 kg |
| Axis travel x | 800 mm |
| Axis travel y | 600 mm |
| Axis travel z | 450 mm |
| Working feed | 0÷10000 mm/1’ |
| Rapids | 10000 mm/1’ |
| Inclination of head | 340° |
| Spindle taper | ISO 40 |
| Speed of spindle | 0÷5000 g/1’ |
| Cnc | SELCA 3045 |
| Maximum power of spindle | 15 Kw |
