Vertical Machining Center QUASER mod. MV204IIL/10
Sold
Vertical Machining Center QUASER mod. MV204IIL/10
Location:Brugali, Italy
Specifications
| Condition | Used |
| Table | 660×1700 mm |
| Axis travel (x) | 1500 mm |
| Axis travel (y) | 660 mm |
| Axis travel (z) | 610 mm |
| Load capacity of the machine | 1500 Kg |
| Cnc | FANUC 18iMB |
| Maximum spindle speed | 10000 min -1 |
| Range number of spindle speed | 1 |
| Rapids | 32000 RPM |
| Speed of rapids | 1-20000 RPM |
| Spindle taper | ISO 40 |
| Tool station | 32 nr |
| Max length of tool | 300 mm |
| Max weight of tool | 7 Kg |
| Height of machine | 3060 mm |
| Weight of machine | 9000 Kg |
| Year of machine | 2004 |
| – coolant system (coolant with high pressure | 20 bar) |
